Product Description
GF3200 Substation Integrated Automation Verification Device (Accuracy class 0.05) Introduction GF3200 substation integrated automation verification device is the massive import integrated circuit and DDS waveform synthesis, high speed digital processor (DSP), complex programmable logical array (CPLD), large scale integrated amplifier, embedded computer system technology and design, inspection device by standard resource, standard table and remote letter box, which has not only has four control (YC, YX, YK, YT) detection function, effect caused by the quantity change the volume test, remote measure, remote communication letter response time test, while testing (adjust value test and frequency atresia test) function,, high precision GPS time setting function, the order of events resolution SOE (SOE in the station，SOE between station) test, in the station SOE storm test function,, during verification, program-controlled exchange source, dc source output functions. Applicable dispatching automation of class, far move class, protection class possesses the character of the device test, is the electric power dispatching system ideal test and calibration equipment. Main features 1, It can be realized remote measure automatic verification through software; 2. Test the same period (adjust value test and frequency atresia test); 3, four control (remote measure, remote communication, remote control, the remote) detection function; 4, To check AC sample device, RTU, PMU, transmitter, indicating meter; 5, To check three-phase watt-hour meter; 6, SOE (the order of events record) resolution test In the station SOE test: verification equipment with high speed CMOS switching a two way interval time can be adjusted up along the pulse, analog devices correctly identify the same two events in the transformer substation. Standing between SOE test: user Settings two moments, control verification equipment respectively to the measurement device sends a pulse system to test the system in the higher level system correctly identify different in the transformer substation two movements events. 7 Remote-sensing letter test Remote letter response time: verification equipment and GPS standard time after time setting, in particular time of the users set to the measurement and control device events, from measurement device to test the equipment action events occur, to detect the time needed for this movement. 8, remote sensing response time test: the verification device GPS standard time after time setting, in particular time of the users set to measurement device of interference in power grid of exchange variables acquisition to test the integrated automation system from the scene happen voltage amplitude. Technical Data 3.1 communication simulation output 3.1.1 AC voltage output Range: 57.7 V, 100 V, 220 V , 380 V; Adjusting range: quantity limit... (0-120) %; Adjust fineness: quantity limit x 0.01%; Accuracy: 0.05% RG; Stability: 0.005% / 1 min. Distortion degree: 0.2% or (not capacitive load); Output load: each phase 25 VA; Load regulation rate: 0.05%. 3.1.2 AC current output Range: 1 A, 2 A, 5 A, 10 A; Adjusting range: quantity limit... (0-120) %; Adjust fineness: quantity limit x 0.01%; Accuracy: 0.05% RG; Stability: 0.005% / 1 min. Distortion degree: 0.2% (not capacitive load); Output load: 25 VA; Load regulation rate: 0.05%. 3.1.3 power output Accuracy: 0.05% RG; Stability: 0.005% / 1 min. 3.1.4 phase angle Adjusting range: 0 ~ 359.999 ; Resolution: 0.001 ; Accuracy: 0.05 . 3.1.5 power factor Adjusting range:-1 ~ 0 ~ + 1; Resolution: 0.0001; Accuracy: 0.0005. 3.1.6 frequency Adjusting range: 45 Hz ~ 65 Hz; Resolution: 0.001 Hz; Accuracy: 0.002 Hz. 3.1.7 three-phase voltage, current symmetric degrees and phase symmetric degrees Voltage, current symmetric degrees:
