Product Details:
Payment & Shipping Terms:
|
Standards: | IEC60044; IEC 61869; ANSI/IEEE C57.13 | Rated Voltage: | 10KV, 6KV |
---|---|---|---|
Rated Load: | ≤150VA | Rated Frequency: | 50Hz Or 60Hz |
Cosø: | 0.8 (lag) | Phase Number: | Single |
Rated Insulation Level: | 12/42/75KV,7.2/32/60KV | Material: | Epoxy Resin |
Weight (kg): | 25 | Class Of Pollution: | II |
GFJDZ1053-10A epoxy resin PT voltage transformer potential instruments power system protection and metering
This model GFJDZX0987-35 potential instrument transformers are cast in epoxy resin and fully enclosed. The units are suitable for electric systems of rated frequency of 50/60Hz and rated voltage of 36kV and below. They are used in indoor service conditions. The products are designed in accordance with Standards IEC60044-2, IEC61869-3 and ANSI/IEEE C57.13.
