GFLZZ0224-10 Single Phase 10/42/75kV High Voltage High Accuracy Protectional Current Transformer
-
-
Large Image :
GFLZZ0224-10 Single Phase 10/42/75kV High Voltage High Accuracy Protectional Current Transformer
|
Product Details:
| Place of Origin: |
Beijing, China |
| Brand Name: |
GFUVE |
| Certification: |
IEC60044; IEC 61869; ANSI/IEEE C57.13 |
| Model Number: |
GFLZZ0224-10 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
3 pieces |
| Price: |
USD 70 / piece |
| Packaging Details: |
standard export carton |
| Delivery Time: |
within 7 days |
| Payment Terms: |
L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: |
100000 pieces per month |
|
Detailed Product Description
| Standards: |
IEC60044; IEC 61869; ANSI/IEEE C57.13 |
Rated Primary Current: |
10-600A |
| Rated Load: |
≤10VA |
Rated Frequency: |
50Hz Or 60Hz |
| Rated Secondary Current: |
5A Or 1A |
Rated Short-time Thermal Current: |
90kA, 1S |
| Rated Dynamic Current: |
200kA |
Rated Insulation Level: |
12/42/75KV |
| FS: |
≤10 |
Material: |
Epoxy Resin |
| Weight (kg): |
22 |
GFLZZ0224-10 Single Phase 10/42/75kV High Voltage High Accuracy Protectional Current Transformer
GFLZZ0224-10 Single Phase 10/42/75kV High Voltage High Accuracy Protectional Current Transformers are fully enclosed and cast in epoxy resin. Transformer is equipped with one core and coil assembly rated for measurement and protection.
The transformers are designed for electric power systems of 50Hz/60Hz rated frequency and 35kV rated voltage. They are used for outdoor mounting. The performances of the products meet standards IEC60044-1, IEC61869-2 and IEEE C57.13. The products are applied to metering electric energy, voltage controlling and relay protection.
