Product Details:
Payment & Shipping Terms:
|
Class: | 0.05 | Types: | Single Phase Smart Meter Test Set |
---|---|---|---|
Current Range: | 0-120A | Voltage Range: | 0-500V |
Frequency: | 40-70Hz | Phase: | 0-360.000 |
Harmonics: | 2-52th U/I | Weight: | 12KG |
LCD: | 7inch Touch TFT Color LCD | TESTING METER: | Automatically Testing Electric Meter |
Meter under testing: 1P2W
2Testing mode: active power, reactive power
Test 3pcs or 2pcs meter synchronously
Start testing and creep testing
Reference standard and power source integrated, easy to carry
Measuring mechanical meter and electric meter
Operating by manual keyboard or PC software
With keyboard shortcuts
Internal large capacity storage device for mass memory
Local checking the testing result
Overload, short circuit, open circuit protection
With self-checking function
Electrical parameters | |
---|---|
Accuracy class | 0.1%, 0.05% |
Power supply | 220V±10% 50/60Hz±2Hz |
Voltage | |
Voltage output | 0-500V |
Power of the voltage output | Max. 30VA |
Resolution | 0.01% |
Accuracy | 0.1%, 0.05% |
Stability | 0.01%/120s |
Distortion factor | <0.1% for linear resistance load |
Current | |
Current output | 1mA-120A, 1mA-60A |
Power of the current output | Max. 100VA, 50VA |
Resolution | 0.01% |
Accuracy | 0.1%, 0.05% |
Stability | 0.01%/120s |
Distortion factor | <0.1% for linear resistance load |
Phase angle | |
Range | 0°-360.00° |
Resolution | 0.01° |
Accuracy | 0.05° |
Frequency | |
Range | 40-70Hz |
Resolution | 0.001Hz |
Accuracy | 0.002Hz |
Pulse output | |
High frequency output(CH) | 36000 |
Low frequency output(CL) | 360 |
Pulse input | |
Input channel | 3 or 2 |
Input frequency | Max. 100KHz |
Mechanical parameters | |
Dimensions (W×D×H) (mm) | 445X440X180 (three meter positions) 410X220X150 (two meter positions) |
Weight (kg) | 15 (three meter positions) 12 (two meter positions) |
Environmental conditions | |
Ambient temperature | -10°C to +40°C |
Relative humidity | 35%-85% |
